Samlex SEC-40BRM Rackmount 40 Amp Regulated Switching Power Supply

          Be the first to write a review
You Pay $426.11
$624.99 Save 32%
Free Shipping
7 In Stock!

Would you like to calculate shipping for this item?

 Samlex SEC-40BRM is an ac-dc power converter that provides a highly regulated dc output voltage of 13.8 volts at 40 amps of continuous power and comes mounted on a 19" 2u size rack plate. See the details tab for more information.

This unit was designed for use with critical power supply applications, telecommunications, mobile sound and audio displays, GPS receivers, security systems and CCTV systems. The output power on this unit can be expanded in steps of 20 amps up to a maximum of 100 amps. An external battery can be connected for back-up and a section of the output current (up to 8 amps) is diverted to charge the batteries when in a state of discharge using the built-in battery back-up module. Features include n+1 redundancy, remote monitoring, and indication by 25-pin sub connector, fan failure warning and alarm indication.FREE SHIPPING IN THE US

  • Comes mounted on a 19" 2u size rack
  • Voltage / amp meter
  • Built-in battery back up module
  • Module status led's, fault indicator led's and fault alarm
  • Number of modules: 2
  • Compact and light weight
  • Cooling: forced air, 2 fans
  • Protections: short circuit, current limit, fan failure, (led and buzzer, input surge protection
  • Power cord: 12 awg / 3 conductor
  • Power cord plug: 125v, 20a, nema 5-20p
  • 2 year warranty



  • Input voltage range : 105 to 125 vac, 50 / 60 hz
  • Input : 8 a
  • Output Voltage : 13.8 vdc
  • Output Voltage : 14 vdc (No load)
  • Output voltage (full load) approx : 13.65 vdc
  • Regulation : 1%
  • Continuous current output : 40 a
  • Surge output current : 46 a
  • Output Current : 48 a (Limit)
  • Maximum battery charging current : 8 a
  • Output ripple : 150mv
  • Output noise : 1 v
  • Fuse : 250 v, 4a
  • Circuit Breaker : 125/250 v, 25a
  • Dimensions : 19"L x 15.9"W x 3.6"H
  • Weight : 20.5 lbs
  • Amps : 40 Amps
  • Brand : Samlex
