Description
A marine power inverter is a must for running AC appliances, tools and other equipment off DC current. But for running or charging sensitive electronics and getting the most out of your power tools, you want the clean electricity provided by a pure sine wave marine inverter.
Specifications
| ac input current maximum | 30 Amps AC |
| ac input voltage range | (MATE Adjustable) 80 to 150 VAC |
| ac output frequency | 60Hz |
| ac output voltage | 120 VAC |
| ac overload capability | Surge: 4800 VA | 5 Sec: 4000 VA | 30 Min: 3200 VA |
| battery charge output | 55 Amps DC |
| certificates | ETL Listed to UL485 |
| continuous ac output current | RMS Output at 25┬░C - 20.8 Amps AC |
| continuous power | 2500 VA |
| dc input voltage range | 21 to 34 VDC |
| dimensions | 13 x 8.25 x 16.25ΓÇ¥ (HxWxL) |
| efficiency | 0.92 |
| idle power | Full: ~20 Watts | Search: ~6 Watts |
| maximum output current | Peak: 70 Amps AC | RMS: 50 Amps AC |
| neutral-ground bond switched | Yes |
| nominal dc input voltage | 24 VDC |
| output voltage regulation | ┬▒2% |
| temperature range | Rated: 0 to 50┬░C (power derated above 25┬░C) | Max: -25 to 60┬░C |
| total harmonic distortion | Typical: 2% | Max: 5% |
| warranty | 5 Year |
| weight | 62 lbs. |
