Cole Hersee 48521 200 Amp Dual Relay

LittelfuseSKU: 48521

Sale price$86.99 Regular price$99.99 Save $13
0 Re-stocking soon Free Shipping


The Cole Hersee 48521 functions as a Normally Off relay or as a latching Relay, depending on which wires are connected by the user.

For use on all vehicle electrical systems such as heavy truck, off-road, construction, material handling, refuse collection or marine. 200A at 12V DC - big enough to control most onboard equipment.

  • Description: Dual Relay
  • Inrush current: 500A for 5 seconds at 12V DC.
  • Control current: 1mA
  • Quiescent current: 2mA
  • Ingress protection: IP67 per IEC 529
  • Ignition protection: to ISO 8846
  • Vibration, shock and EMI/RF: to SAE J1455
  • Function: Can be wired as a Normally Off Relay or a Latching relay
  • Continuous current: 200A at 12V DC
  • Stud terminals: 5/16-18, torque 65 in-lbs (7.34Nm)
  • Weight: 2 lbs
  • Warranty: 1 year


amps 200 Amps
