Description
WF-8900 Series Power Center from WFCO Electronics. See details for mroe information.
Specifications
| ac circuits (twin breakers) | 1 main and 5 branch circuits |
| bulk charge voltage | Quick charge 14.4V DC (quick charging voltage) |
| case color | Brown |
| case material | Plastic |
| certifications | FCC |
| converter type | Three-Stage Converter Charger |
| cooling system | Yes |
| dc circuits (quantity) | (2 30A max), 11 (9 20A max) |
| float voltage | 13.2V DC (trickle charge voltage) |
| input voltage | 105-130 VAC, 60 Hz |
| nominal voltage | 13.6V DC (nominal voltage) |
| output current | 35 A |
| output power | 600 W |
| over current | Yes |
| over temperature | Yes |
| over voltage | Yes |
| reverse polarity | Yes |
| voltage output | 13.2 ΓÇô 14.4V DC Range |
