Description
This powerful lithium iron phosphate battery is ready to replace your heavy lead-acid battery bank in your sailboat, RV or solar energy system. The RB200 gives you the flexibility to replace several small, heavier lead-acid batteries in a single high-capacity unit. This item ships directly from the manufacturer.
|
ELECTRICAL SPECIFICATIONS |
|
|---|---|
| Nominal Voltage | 12.8 V |
| Nominal Capacity | 200 Ah |
| Capacity @ 25 A | 480 min |
| Energy | 2560 Wh |
| Resistance | 30 mΩ @ 50% SOC |
| Efficiency | 99% |
| Self Discharge | <3% per Month |
| Maximum Batteries Connected in Series | 6 |
|
MECHANICAL SPECIFICATIONS |
|
|---|---|
| Dimensions (L x W x H) | 20.6 x 10.5 x 8.7” (520.8 x 267.8 x 221 mm) |
| Weight | 61.1 lbs (27.7 kg) |
| Terminal Type | M8 x 1.25 x 2mm |
| Terminal Torque | 80 - 100 in-lbs (9 - 11 N-m) |
| Case Material | ABS and Polycarbonate blend (UL94-V0 flame rating) |
| Enclosure Protection | IP67 |
| Cell Type - Chemistry | Cylindrical - LiFePO4 |
