Description
LFPGLF105, Golf Cart Battery 48VDC 105Ah Lithium with wiring kit
Powerful Performance: Delivers 5.3 kWh of energy, replacing most lead-acid batteries as a drop-in replacement. Delivers full amp capacity and no memory problems.
Enhanced Capability: Struggling with extra cart weight or course incline? No problem! With 400A/20.48kW surge power for 10 seconds, maximize your speed effortlessly, and with a built in heater, you can charge in lower temperatures.
Efficiency: Enjoy the same run time as multiple batteries, but with just one battery at half the weight.
Longevity: Boasts 8x more charging cycles than lead batteries, significantly reducing installation and replacement costs.
Peace of Mind: Backed by a 10-year prorated warranty for safe, reliable, and powerful performance.
10 Year prorated warranty from manufacturer
Built in heater for charging in extreme temperatures
Stable output voltage & full amp capacity
Low maintenance
BMS loaded with safety features
Cell balancing
Battery voltage monitoring
Battery current monitoring
Low self discharge
On/off power switch
IP67 water resistant
Battery temperature monitoring (integrated temperature sensor in BMS)
COM port for digital display
High surge capacity
Includes mounting bracket, powerful charger, wiring kit
Model # LFPGLF105A
Nominal Voltage (48V)51.2V
Capacity (Ah) 105Ah
Battery Energy 5376Wh
Self Discharge ?3% per month at 25 C
Cycle Life >4000 cycles
Charge Mode CC/CV
Charge Cut-off Voltage 58.4V
Recommended Charge 20A-50A
Max Continuous Charge 100A
Max Continuous Discharge 200A
Max Pulse Current 400A/10S
Discharge Cut-off Voltage 35.2V
Storage Temperature 0~45 C
Working Environment 0? C~+55 C (Charge)
(-)20 C~+65 C (Discharge)
Charge Low Temp Protection (-)10 C | 14 F
Charge Low Temp Protection Release 0 C | 32 F
Charge High Temp Protection Alarm 65 C | 149 F 60 C | 140 F
Charge High Temp Protection Release 45 C | 113 F
Housing Material Powder Coated Seal
LCD display Yes
Dimensions (L*W*H (IN)) 18*13.25*9.75
WEIGHT 76 lb
