Description
Engineered for demanding environments, this inverter delivers a massive 12,000-watt surge capacity for 20 seconds, ensuring reliable startup for heavy-duty equipment. Advanced DSP (Digital Signal Processing) technology maintains consistent performance and stable output voltage—even as battery levels drop—making it ideal for sensitive electronics, power tools and appliances. Built tough for rugged conditions, it features an intelligent 3-step controlled fan for efficient cooling, dual GFCI outlets for added safety, and an optional LCD remote panel for convenient monitoring.
Ideal for professional-grade applications:
- Utility and service trucks requiring grid-quality power
- Mobile workshops, food trucks, and field service vehicles
- Off-grid homes, cabins, and emergency backup systems
- Remote construction sites and solar/battery backup installations
Features:
- 4000W Continuous Power – Handles demanding loads with ease
- 12,000W Surge Capacity – Powers high-startup equipment for 20 seconds
- ETL Listed Confirms to UL458 Standards & CSA
- Pure Sine Wave Output – Clean power safe for most devices
- Single GFCI Duplex receptacle – Enhanced safety protection
- Hard wire terminal for full output capacity
- DSP Technology – Advanced digital signal processing for optimal performance
- Harsh Environment Ready – Built to withstand tough conditions
- 3-Step Controlled Fan – Quiet operation with efficient cooling
- Voltage Regulation – Stable output regardless of battery voltage fluctuations
- Optional LCD display for convenient monitoring- REMOTELF
- Power Save Mode – Energy conservation when no load present
- Overload protection
- Low and high voltage protection
- Short circuit protection
- Low and high temperature protection
- Conformal coated
- 50Hz & 60Hz
- 2 Year Warranty
- Lifetime Tech support
Specifications:
- Continuous Power Watt: 4000
- Surge Rating(20s) Watt: 12000
- Capable of Electric Motor: 4.0HP
- Output Waveform: Pure Sine wave
- Nominal Efficiency: Up to 88%
- Power Factor: 0.9-1.0
- Nominal Output Voltage: 120Vac (Single Phase) or 120/240Vac (Split Phase PILF30W12V240V ONLY)
- Output Voltage Regulation: ±10% RMS
- Output Frequency: 50/60Hz ± 0.3Hz
- Short Circuit Protection: Yes, Current Limit Function (Fault after 1sec)
- THD: Typically-<3%, Max 10% under full linear load
- Nominal Input Voltage: 12.0Vdc
- Minimum Start Voltage: 10.0Vdc
- Low Battery Alarm: 10.5Vdc / 11.0Vdc /11.5Vdc / 12.5Vdc
- Low Battery Trip: 10.0Vdc / 10.5Vdc /11.0Vdc / 12.0Vdc
- High Voltage Alarm & Fault: ≥16.0Vdc
- High DC Input Recovery: ≤15.5Vdc
- Low Battery Voltage Recover: ≥13.0Vdc
- Idle Consumption-Search Mode: < 2.5W when Power Saver On Mode
- Remote Control: Yes. Optional
- Display: Tri-Color LEDs
- Mounting: Wall Mounted or Flat Placement- Any orientation except upside down (top facing down)
