Description
FRAM Extra Guard Oil Filter PH5
FRAM Extra Guard oil filters deliver advanced engine protection for everyday drivers who perform routine oil changes at OE (original equipment) recommended intervals.
Equipped with SureGrip technology, FRAM Extra Guard oil filters provide a non-slip surface allowing for easy install and removal. The silicone anti-drain back valve ensures safe engine startups, extending the life of the oil filter for up to 10,000 miles (16,000 kilometers).
- Proven protection for up to 10,000 miles (16,000 kilometers)
- Engineered for use with synthetic or conventional motor oils
- SureGrip technology for easy install and removal
- Filter media is a blend of fiber and resin that captures 95% of the dirt particles
- Silicone anti-drain back valve helps ensure safe engine start up
- *FRAM Group testing of average filter efficiency of PH8A, PH3387A and PH4967 under ISO 4548-12 for particles greater than 20 microns.
- **Greater than 3X the functional life of Nitrile ADB when tested per SAE HS806 hot oil and Anti-drain-back test.
Height: 5.172 in.
Outside Diameter: 3.781 in.
Anti-Drain Back Valve: Yes
Bypass Relief Valve: No
Gasket Inside Diameter: 3.140 in.
Gasket Outside Diameter: 3.563 in.
Gasket Thickness: 0.250 in.
Gasket Type: Base
Attachment Type: Spin-On
Burst Pressure (Pounds per Square Inch): 230.000
Filter Media Material: Cellulose/Synthetic Blend
Inlet Type: Threaded
Inside Thread Diameter: 13/16-16 in.
Thread Size: Standard
Torque Nut: No
