Description
AIMS Power PICOGLF30W12V120VR 3000 Watt 12V Pure Sine Inverter Charger. 3000 watt low frequency inverter.
Specifications
| charger rate | 100A |
| continuous output power | 3000 Watts |
| dimensions | 16.48 L x 8.74 W x 7.1 H inches |
| frequency | 50Hz +/- 0.3Hz / 60Hz +/- 0.3Hz |
| high voltage alarm | 16.0Vdc |
| idle consumption | 55 Watts |
| input voltage | 12 Volts |
| line mode efficiency | >95% |
| low battery alarm | 10.5Vdc-11.0Vdc |
| low battery trip | 10.0Vdc-10.5Vdc |
| low battery voltage restart | 15.5Vdc |
| minimum start voltage | 10.0Vdc |
| nominal efficiency | >88% (Peak) |
| output voltage | Depends on battery Type |
| surge rating | 9000 Watts (20 Seconds) |
| thd | < 10% DC |
| typical transfer time | 10ms (Max) |
| waveform | Pure Sine Wave |
| weight | 58 lbs. |
